ZKR型直线振动筛产品广泛应用于化工、食品、塑料、医药、冶金、玻璃、建材、粮食、化肥、磨料、陶瓷等行业中干式粉状或颗粒状物料的筛分。
    ZKR type linear vibrating screen products are widely used in chemical, food, plastics, medicine, metallurgy, glass, building materials, food, chemical fertilizer, abrasive, ceramic and other industries dry type sieving powder or granular materials
    ZKR型直线振动筛采用双振动电机驱动,当两台振动电机做同步、反缶旋转时，其偏心块所产生的激振力在平行于电机轴线的方向相互抵消，在垂直于电机轴的方向叠为一合力，因此筛机的运动轨迹为一直线。其两电机轴相对筛面有一倾角，在激振力和物料自重力的合力作用下，物料在筛面上被抛起跳跃式向前作直线运动，从而达到对物料进行筛选和分级的目的。 可用于流水线中实现自动化作业。具有能耗低、效率高、结构简单、易维修、全封闭结构无粉尘溢散的特点。最高筛分目数400目，可筛分出7种不同粒度的物料。
    ZKR直线筛筛分精度高、处理量大、结构简单、耗能少、噪音低、筛网使用寿命长、密封性好、极少粉尘溢散、维修方便、可用于流水线生产中的自动化作业。
    ZKR type linear vibrating screen with double vibration motor drive,when the two vibrating motors works synchronization and do not help rotates, the vibration force produced by eccentric block in parallel to the direction of the motor axis offset each other, in the fold is perpendicular to the direction of the motor shaft for a resultant force, so the trajectories of screen machine for a straight line.The two motor shaft relative screen surface has a angle, the vibration force and material since the gravitational force, under the action of the material on the screen was thrown up by leaps and bounds ahead for linear motion, so as to achieve the purpose of the screening and grading the supplies.Can be used in the assembly line automation in operation.Low energy consumption, high efficiency, simple structure, easy maintenance, fully closed structure, no dust overflow scattered characteristics.Highest screen mesh 400 mesh, screening out 7 in different particle size of materials.
   ZKR linear screen screening of high precision, large capacity, simple structure, less energy consumption, low noise, long duration, good sealing, little dust overflow scattered, convenient maintenance, in the production of automation can be used in the assembly line.

ZKR直线振动筛技术参数

Parameters

型号	筛面层数	筛网面积(㎡)	筛孔尺寸(mm)	最大给料粒度(mm)	处理能力(m3/h)	振动频率(Hz)	双振幅(mm)	电机功率(kw)
ZKR1230	1	3.6	0.25～13	150	5～40	16	7～9	5.5×2
2ZKR1230	2	3.6×2	0.25～13	150	5～40			5.5×2
ZKR1445	1	6.3	0.25～50	300	10～210			7.5×2
2ZKR1445	2	6.3×2	0.25～50	300	10～210			11×2
ZKR1645	1	7.2	0.25～50	300	14～250			11×2
2ZKR1645	2	7.2×2	0.25～50	300	14～250			15×2
ZKR1652	1	8.4	0.25～50	250	90～270			11×2
2ZKR1652	2	8.5	0.25～50	250	90～270			15×2
ZKR1845	1	8.1	0.25～50	300	18～324			15×2
2ZKR1845	2	8.1×2	0.25～50	300	18～324			18.5×2
ZKR2045	1	9	0.25～50	300	21～360			18.5×2
2ZKR2045	2	9×2	0.25～50	300	21～360			22×2
ZKR2060	1	12	0.25～50	300	24～480			18.5×2
2ZKR2060	2	12×2	0.25～50	300	24～480			22×2
ZKR2445	1	10.8	0.25～50	300	21～432			22×2
2ZKR2445	2	10.8×2	0.25～50	300	21～432			22×2
ZKR2452	1	12.6	0.25～50	300	25～504			22×2
2ZKR2452	2	12.6×2	0.25～50	300	25～504			22×2
ZKR2460	1	14.4	0.25～50	300	27～540			22×2
2ZKR2460	2	14.4×2	0.25～50	300	27～540			22×2
ZKR3045	1	13.5	0.25～50	300	31～630			22×2
2ZKR3045	2	13.5×2	0.25～50	300	31～630			30×2
ZKR3052	1	15.6	0.25～50	300	36～720			30×2
2ZKR3052	2	15.6×2	0.25～50	300	36～720			30×2
ZKR3060	1	18	0.25～50	300	32～648			30×2
2ZKR3060	2	18×2	0.25～50	300	32～648			30×2
ZKR3645	1	16.2	0.25～50	300	37～756			30×2
2ZKR3645	2	16.2×2	0.25～50	300	37～756			37×2
ZKR3652	1	18.9	0.25～50	300	42～846			30×2
2ZKR3652	2	18.9×2	0.25～50	300	42～846			37×2
ZKR3660	1	21.6	0.25～50	300	54～1080			30×2
2ZKR3660	2	21.6×2	0.25～50	300	54～1080			37×2
